SolidWorks Projects with Documentation
You will always find the updated list of top and best free SolidWorks projects with source code in an easy and quick way. Our Free SolidWorks projects list has projects for beginners, intermediates as well as experts to learn in 2023.
SolidWorks, a flagship CAD software, empowers engineers and designers to visualize and realize their creations in three-dimensional space. Its comprehensive suite of tools enables the development of intricate models and simulations, driving innovation in product design.
SolidWorks projects provides educational opportunities for college students who wants to acquire new skills and knowledge because they let you learn a lot without paying. You need to be dedicated, curious and take the lead in your learning to get the most out of these free SolidWorks projects.
We have provided multiple complete SolidWorks Projects for any university student to enhance more knowledge about their SolidWorks project and to score better marks in their college exams.
College students can easily make use of all these SolidWorks Projects with Source Code and documentation by downloading them. These SolidWorks Projects with Source Code will help you tremendously in preparation of your own college projects.
1. Solidworks Design & Simulation of 360 Degree Flexible Drilling Machine
Drill machines have been the heart of every industry. Drilling holes in parts, sheets and structures is a regular industrial work. Perfect and well aligned drilling needs fixed and strong drills.
Some parts cannot be drilled using fixed drills due to low space between drill bit and drill bed. We need to use hand drills in such cases but hand drills have alignment problems while drilling.
So here we propose a 360 degree flexible drill that can be mounted on a table or wall and can be used to drill holes horizontally, vertically or even upside down.
So this makes it possible for easy drilling in even complicated parts and surfaces. Thus we use rotating hinges and connectors with motor mount and supporting structure to design and fabricate a mini 360 degree drill for easy drilling operations.
2. Solidworks Design & Simulation of Staircase Climbing Trolley
Goods transportation locally is highly dependent on manual trolleys. They are used in warehouses, construction sites, malls, residential relocations etc. These trolleys have a very huge limitation when it comes to stairs.
They can only move on flat surfaces and moving them over a staircase is a very hectic task. So here we propose a smartly designed staircase climbing trolley.
The trolley is smartly designed to carry goods up and down on staircases as well as on flat grounds and even rough terrains. The trolley makes use of a triple interlinked wheel arrangement that allows it to do so.
The mechanism uses a trolley with a support wheel arrangement which will be used for support when at rest and will be suspended in air while the trolley is moved by lifting it.
3. Solidworks Design & Simulation of Box Transport Mechanism
This Box Transport Mechanism Project task utilizes system for moving stuffed merchandise one by one among which some action can be conveyed like examination, shutting, naming and so forth among the travel and will move the products one by one by the bar linkages.
This entire box shifting mechanism project is comprised of gentle steel material. Numerous connections are used to move the case forward, the fundamental connection is associated with the engine which changes over the turning movement into liner, which responds movement for the shifter joins.
Thus, this project can be used in many industrial purposes, the box shifting mechanism has a time delay between moving packages and this delay can be used to introduce any alterations in the package or help in moving the package for any other purpose.
4. Solidworks Design & Simulation of Power Generating Speed Breakers
A large amount of energy is wasted by the vehicles on the speed breakers through friction, every time it passes over it. Energy can be produced by using the vehicle weight and speed.
So here we propose a smart speed breaker that generates power. The reciprocating motion of the speed breaker is converted into rotary motion using the rack and pinion arrangement.
We design a smart speed breaker that can pass vehicles coming from both sides and yet generate energy from it. The system makes use of mechanical assembly with metal sheets with linkages that press down with spring arrangement.
The system makes use of the speed breaker press and then uses a rack and pinion arrangement to press down and run generator motor thus generating energy. The spring mechanism is the used to drive the speed breaker back into original position.
5. Solidworks Design & Simulation of Electricity Generator Tiles
Solar energy comes with a condition, like it creates energy only in the presence of sun rays, it requires heat to generate kinetic energy and same with wind energy it requires wind to be blown all the time to generate kinetic energy.
This energy can be used in particular places only. Kinetic energy is the energy of motion and can therefore be found in every object that moves. So, in this power generating tiles project we are making use of tiles to generate electricity.
Generating off-grid electricity just by walking around or powering streetlights with your footsteps. It consists of spring, gears, two rack and pinion and three generators.
The system makes use of rack and pinion arrangement coupled with efficient gearing mechanism to drive mini generators that produce energy when pressed. We make use of harvested kinetic energy generated through vertical press foot movement.
6. Solidworks Design & Simulation of Pneumatic Power Steering System
Pneumatic machinery are machines and tools which use air pressure to do work. In this type of machine, high pressure compressed air is transmitted throughout the machine to pneumatic actuator.
The air is controlled directly by control valves and distributed through the tubes. This system consists of pneumatic actuator, two wheels and power steering linkage mounting on frame.
There pneumatic actuator shaft is linked to one of the wheels. The other wheel is attached with linkage mounting. Pneumatic cylinder stroke is controlled by Direction control lever, and steering occurs.
Pneumatic Power Steering System makes it very easy to drive the vehicle than the vehicle which currently uses fluid power and also these vehicles can be maintained easily.
7. Solidworks Design & Simulation of 360-Degree Rotating Vehicle
This project is about 360-degree rotating vehicle. This vehicle moves in all directions and this design provides better comfort and also saves the time, most of the people uses this vehicle to carry goods, emergency patients etc.
The normal wheel vehicles face lot of problems like parking, U turn and much more which consumes more time. So, we have designed a 360-degree wheel rotating vehicle to reduce and eliminate problems in the industry as well as common life of people.
The vehicle can take a turn without moving the vehicle. No extra space is required to turn the vehicle. In this system, each of the 4 wheels has given drive with DC motors, so it can rotate 360 degree. 360-degree rotating wheel is controlled by RF remote.
8. Solidworks Design & Simulation of Power Generator Forearms Machine
Our system makes use of the gripping rod connected to spring based motorized mechanism having rack pinion arrangement and multiple motors to power the system and generate power.
The system aims to provide resistance to forearms movement while generating power from the same thus serving dual purpose. The machine makes use of 3 motor arrangement to provide 3 levels of generation capability.
The machine aims to generate electricity through horizontal motion created while working our forearms. The spring based mechanism allows for efficient resistance settings in the machine as needed. Increased resistance leads to increased power generation in the machine.
9. Solidworks Design & Simulation of Six Legged Spider Bot using Klann Mechanism
The kinematics of this robot will allow it to move on different terrain at different speeds. It has six links per leg 180 degrees of crank rotation per stride. The linkage consists of the frame, crank, two pivoted rockers, and two couplers all connected by pivot joints.
The kinematics of robots structure enables it to convert the rotating motion of the crank into the movement of foot similar to that of creature strolling.
The most important benefit of this mechanism is that, it does not require microprocessor, controller and other actuator mechanisms. By copying to the physical structure of legged animals, it may be possible to improve the performance of the mobile robots.
10. Solidworks Design and Simulation of Dual Side Shaper Machine
In a dual shaper machine, materials are shaped from both sides, which makes it more advantageous than usual shaper. Dual Shaper machine helps industries to achieve high production rate at a minimal amount of time and cost.
Dual Shaper machine reduces the production cost as well as the time. In this project, a dual side shaper machine is designed with the help of quick return mechanism, the rotary motion of the motor is converted into linear motion of the tool which shapes the material mounted on the vice from both the side.
The quick return mechanism converts rotary motion into reciprocating motion, but unlike the crank and slider, the forward reciprocating motion is at slower rate than the return stroke.
DC motor is connected with the mechanism with the help of chain and sprocket. Whole mechanism is built on rugged metal frame.
So, these are the Top 10 Best SolidWorks Projects with Documentation available online. We hope our SolidWorks Projects with source code has helped you. Please share these SolidWorks Projects with your friends as well 🙏
